    Welcome to the official website of Lihong Safety Equipment Engineering (Shanghai) Co., Ltd.!





















    Position首頁 > Home > Industrial Safety Products > Sensor > Safety Light Curtain





    LC4 cascade safety grating


    ·Security level reaches Type 4, PLe.
    ·The protection height is 140mm to 1420mm.
    ·A protection system consisting of a set of main gratings and 1 ~ 3 sets of auxiliary gratings, transmission lines and accessories.
    ·Four sets of gratings can be connected in series, and the total number of beams can reach 288 at most.
    ·Can realize the "serial setting" with increased detection height
    ·Set ",L-shaped setting and U-shaped setting of multi-sided protection.
    ·Pass TUV safety certification

    ▊Directives and standards
    EU directive
    Machinery Safety Directive 2006/42/EC and EMC Directive 2014/30/EUU
    European Standards
    EN 61496-1、EN 61496-2、EN 13849-1、EN 61326-1
    international standard
    IEC 61496-1、IEC 61496-2、ISO 13849-1、IEC 61326-1、ISO 13855
    national standard
    GB/T 19436.1、GB/T 19436.2、GB 4584

    ▊specifications and models
    Main optical grating
    serial number
    model
    Optical axis spacing
    Detection accuracy
    Detection distance
    Grating type
    7
    LC4-10-0480mm-Z
    10
    15
    0-6m
    Main grating
    8
    LC4-10-0520mm-Z
    10
    15
    0-6m
    Main grating
    9
    LC4-10-0560mm-Z
    10
    15
    0-6m
    Main grating
    10
    LC4-10-0600mm-Z
    10
    15
    0-6m
    Main grating
    11
    LC4-10-0640mm-Z
    10
    15
    0-6m
    Main grating
    12
    LC4-10-0680mm-Z
    10
    15
    0-6m
    Main grating
    13
    LC4-10-0720mm-Z
    10
    15
    0-6m
    Main grating
    14
    LC4-10-0760mm-Z
    10
    15
    0-6m
    Main grating
    15
    LC4-10-0800mm-Z
    10
    15
    0-6m
    Main grating
    16
    LC4-20-0240mm-Z
    20
    26
    0-6m
    Main grating
    17
    LC4-20-0280mm-Z
    20
    26
    0-6m
    Main grating
    18
    LC4-20-0320mm-Z
    20
    26
    0-6m
    Main grating
    19
    LC4-20-0360mm-Z
    20
    26
    0-6m
    Main grating
    20
    LC4-20-0400mm-Z
    20
    26
    0-6m
    Main grating
    21
    LC4-20-0440mm-Z
    20
    26
    0-6m
    Main grating
    22
    LC4-20-0480mm-Z
    20
    26
    0-6m
    Main grating
    23
    LC4-20-0520mm-Z
    20
    26
    0-6m
    Main grating
    24
    LC4-20-0560mm-Z
    20
    26
    0-6m
    Main grating
    25
    LC4-20-0600mm-Z
    20
    26
    0-6m
    Main grating
    26
    LC4-20-0640mm-Z
    20
    26
    0-6m
    Main grating
    27
    LC4-20-0680mm-Z
    20
    26
    0-6m
    Main grating
    28
    LC4-20-0720mm-Z
    20
    26
    0-6m
    Main grating
    29
    LC4-20-0760mm-Z
    20
    26
    0-6m
    Main grating
    30
    LC4-20-0800mm-Z
    20
    26
    0-6m
    Main grating
    31
    LC4-20-0840mm-Z
    20
    26
    0-6m
    Main grating
    32
    LC4-20-0880mm-Z
    20
    26
    0-6m
    Main grating
    33
    LC4-20-0920mm-Z
    20
    26
    0-6m
    Main grating
    34
    LC4-20-0960mm-Z
    20
    26
    0-6m
    Main grating
    35
    LC4-20-1000mm-Z
    20
    26
    0-6m
    Main grating
    36
    LC4-20-1040mm-Z
    20
    26
    0-6m
    Main grating
    37
    LC4-20-1080mm-Z
    20
    26
    0-6m
    Main grating
    38
    LC4-20-1120mm-Z
    20
    26
    0-6m
    Main grating
    39
    LC4-20-1160mm-Z
    20
    26
    0-6m
    Main grating
    40
    LC4-20-1200mm-Z
    20
    26
    0-6m
    Main grating
    41
    LC4-20-1240mm-Z
    20
    26
    0-6m
    Main grating
    42
    LC4-20-1280mm-Z
    20
    26
    0-6m
    Main grating
    43
    LC4-20-1320mm-Z
    20
    26
    0-6m
    Main grating
    44
    LC4-20-1360mm-Z
    20
    26
    0-6m
    Main grating
    45
    LC4-20-1400mm-Z
    20
    26
    0-6m
    Main grating
    46
    LC4-20-1440mm-Z
    20
    26
    0-6m
    Main grating
    47
    LC4-20-1480mm-Z
    20
    26
    0-6m
    Main grating
    48
    LC4-20-1520mm-Z
    20
    26
    0-6m
    Main grating
    Sub-grating
    serial number
    model
    Optical axis spacing
    Detection accuracy
    Detection distance
    Grating type
    1
    LC4-10-0260mm-F
    10
    15
    0-6m
    Sub-grating
    2
    LC4-10-0300mm-F
    10
    15
    0-6m
    Sub-grating
    3
    LC4-10-0340mm-F
    10
    15
    0-6m
    Sub-grating
    4
    LC4-10-0380mm-F
    10
    15
    0-6m
    Sub-grating
    5
    LC4-10-0420mm-F
    10
    15
    0-6m
    Sub-grating
    6
    LC4-10-0460mm-F
    10
    15
    0-6m
    Sub-grating
    7
    LC4-10-0500mm-F
    10
    15
    0-6m
    Sub-grating
    8
    LC4-10-0540mm-F
    10
    15
    0-6m
    Sub-grating
    9
    LC4-10-0580mm-F
    10
    15
    0-6m
    Sub-grating
    10
    LC4-10-0620mm-F
    10
    15
    0-6m
    Sub-grating
    11
    LC4-10-0660mm-F
    10
    15
    0-6m
    Sub-grating
    12
    LC4-10-0700mm-F
    10
    15
    0-6m
    Sub-grating
    13
    LC4-10-0740mm-F
    10
    15
    0-6m
    Sub-grating
    14
    LC4-10-0780mm-F
    10
    15
    0-6m
    Sub-grating
    15
    LC4-10-0820mm-F
    10
    15
    0-6m
    Sub-grating
    16
    LC4-20-0250mm-F
    20
    26
    0-6m
    Sub-grating
    17
    LC4-20-0290mm-F
    20
    26
    0-6m
    Sub-grating
    18
    LC4-20-0330mm-F
    20
    26
    0-6m
    Sub-grating
    19
    LC4-20-0370mm-F
    20
    26
    0-6m
    Sub-grating
    20
    LC4-20-0410mm-F
    20
    26
    0-6m
    Sub-grating
    21
    LC4-20-0450mm-F
    20
    26
    0-6m
    Sub-grating
    22
    LC4-20-0490mm-F
    20
    26
    0-6m
    Sub-grating
    23
    LC4-20-0530mm-F
    20
    26
    0-6m
    Sub-grating
    24
    LC4-20-0570mm-F
    20
    26
    0-6m
    Sub-grating
    25
    LC4-20-0610mm-F
    20
    26
    0-6m
    Sub-grating
    26
    LC4-20-0650mm-F
    20
    26
    0-6m
    Sub-grating
    27
    LC4-20-0690mm-F
    20
    26
    0-6m
    Sub-grating
    28
    LC4-20-0730mm-F
    20
    26
    0-6m
    Sub-grating
    29
    LC4-20-0770mm-F
    20
    26
    0-6m
    Sub-grating
    30
    LC4-20-0810mm-F
    20
    26
    0-6m
    Sub-grating
    31
    LC4-20-0850mm-F
    20
    26
    0-6m
    Sub-grating
    32
    LC4-20-0890mm-F
    20
    26
    0-6m
    Sub-grating
    33
    LC4-20-0930mm-F
    20
    26
    0-6m
    Sub-grating
    34
    LC4-20-0970mm-F
    20
    26
    0-6m
    Sub-grating
    35
    LC4-20-1010mm-F
    20
    26
    0-6m
    Sub-grating
    36
    LC4-20-1050mm-F
    20
    26
    0-6m
    Sub-grating
    37
    LC4-20-1090mm-F
    20
    26
    0-6m
    Sub-grating
    38
    LC4-20-1130mm-F
    20
    26
    0-6m
    Sub-grating
    39
    LC4-20-1170mm-F
    20
    26
    0-6m
    Sub-grating
    40
    LC4-20-1210mm-F
    20
    26
    0-6m
    Sub-grating
    41
    LC4-20-1250mm-F
    20
    26
    0-6m
    Sub-grating
    42
    LC4-20-1290mm-F
    20
    26
    0-6m
    Sub-grating
    43
    LC4-20-1330mm-F
    20
    26
    0-6m
    Sub-grating
    44
    LC4-20-1370mm-F
    20
    26
    0-6m
    Sub-grating
    45
    LC4-20-1410mm-F
    20
    26
    0-6m
    Sub-grating
    46
    LC4-20-1450mm-F
    20
    26
    0-6m
    Sub-grating
    47
    LC4-20-1490mm-F
    20
    26
    0-6m
    Sub-grating
    48
    LC4-20-1530mm-F
    20
    26
    0-6m
    Sub-grating






    Related Products








    Download





    PDF file download





    Video file download
